Bonavera CHEM 200
Manufacture by Beacon
- A complete range of reagents for all hematology analyzers
- Fully compatible with all hematology analyzers
- Long shelf life and stability
- Economical, cost effective with superior quality
- Liquid stable ready to use reagents
Product Description
Other Details:
Salient Features:
Reagent & Sampling Compartment:
Multifunctional Probe for Reagent / Sample:
Homogenous Mixing:
Reaction Area & Optical System:
Advance Operating System:
Better Usability:
- Long lasting consistency
- Precision & accuracy
- Powerful backup
- Ease of use
- Economy
Salient Features:
- Fully automated, discrete, random access biochemistry analyzer
- Throughput upto 200 test per hour with STAT facility
- On board laundry as well as on board cooling facilities
- Advance user-friendly operating system
- Long lasting durable optical system using IFCOS
- Integrated barcode reagent system
Reagent & Sampling Compartment:
- Equipped with onboard cooling facility
- 40 reagent position using dedicated bottle types
- 40 sample position which can accommodate all types of sample cups, Primary Tubes, Blood Collection Tubes (Clot Activator)
Multifunctional Probe for Reagent / Sample:
- Internally & externally polished to resist carryover
- Specially designed waterfall washing system
- Equipped with vertical collision protection & auto depth adjustment
Homogenous Mixing:
- Specially designed Teflon Coated Mixture with standardized step procedure for uniform mixing
- Smooth coating prevents water dropping & cross contamination
Reaction Area & Optical System:
- 44 Semi Permanent & Reusable Pyrex Cuvettes which can run for >1500 tests
- Reaction Volume from 150 µl to 350 µl
- Cuvette washing by On Board Laundry facility using 2 Step 6 Stop washing
- Cuvette Integrity Check at all wavelengths before the analysis
- Reaction Area with unique Air Incubation system to maintain the Temperature of 37° ± 0.1° C
- Integrated Fully Closed Optical System with 8 Short Bandwidth Interference filters.
Advance Operating System:
- Easy to Use Window Base Operating System
- On Line Reaction & Calibration Curve
- Reagent Inventory Management System
Better Usability:
- Easy Lamp Assembly Changing Facility
- Separate power switch for refrigeration compartment
Product Specification
| Automation | Fully Automatic |
| Brand | BioGeny |
| Model Name/Number | Bonavera Chem 200 |
| Power Supply | AC 110/220V +10% 50/60 Hz 650W Online UPS (230V) with isolated transformer 2 kVA |
| Wavelength | 340nm, 405nm, 450nm, 505nm, 546nm, 578nm 630nm, 700nm |
| Sample Volume | 2-30 micro L, step by 0.1 micro L |
| Weight | 80 kg |
| Light Source Lamp | Halogen Lamp |
| Resolution | 0.0001 Abs |
| Dimension | 870 x 690 x 740 mm (L x W x H) |
| Data Processing | Automatic Calibration, Blank Deduction, Dirty Cuvette Memory, Editable, Ref Range, Panel Test etc |
| Report Printing | 6 formats optional TCP/IP network interfacing |
| Operating System | Windows 7, Windows 8, Windows 10 |
| Absorbance Range | 0-4 |
| Sample Tube | Micro cup & test tube, blood collection tube can also be used |
| Sample Tray | 40 Sample Positions |
| Reagent Tray | 40 reagent positions with constant temperature 2-14 DegreeC |
| Reagent Volume | 20-300 micro L, step by 1 micro L |
| Reagent Needle | Reagent volume detection, Collision protection |
